Model:PHZ-F020306-BW202 Huawei /Amphnol card edge connector-Power blade connetor blade power connector powerblade connector healthy connector mass health connector wire connector ma health connector battery terminal connector

Product Overview

1. Materials: Rubber shell: thermoplastic high-temperature resistant plastic, U94-V0, black: Terminal: copper alloy; Nut: stainless steel; 2. Electroplating: gold is electroplated in the contact area, tin is electroplated in the welding area, and all nickel bottoms are formed; 3. Electrical performance requirements: AC rated current: 30A; DC rated current: 100A; Rated signal current: 1A; AC terminal rated voltage: 420VAC; DC rated voltage: 72VDC; Signal rated voltage: 72VDC; Contact resistance of AC terminal: 5mΩMax; Contact resistance of DC terminal: 1mΩ Max; Contact resistance of signal terminal: 30mΩ Max; Insulation resistance: 1000mΩ Min; 4. The products meet the latest RoHS standards. Name: High-power golden finger connector (AC, DC-M4 nut) Model:PHZ-F020306-BW202

Key Features

• Materials: Rubber shell: thermoplastic high-temperature resistant plastic, U94-V0, black: Terminal: copper alloy;
• Electroplating: gold is electroplated in the contact area, tin is electroplated in the welding area, and all nickel bottoms are formed;
• Electrical performance requirements: AC rated current: 30A;
• AC terminal rated voltage: 420VAC;
• Signal rated voltage: 72VDC;

Technical Specifications

Applications

Server and AI compute power shelves, UPS and distributed power supplies, telecom and data centre equipment, energy storage systems, EV charging piles, solar inverters, industrial power distribution and medical instrumentation.
